CY-VI-A6000 PET Hot filling bottle blowing machine

CY-VI-A6000 PET Hot filling bottle blowing machine

Quick Details
Place of Origin: China (Mainland) Brand Name: trueeasy Model Number: CY-II-A6000
Plastic Processed: PET Application: Bottle Blow Moulding Type: Stretch Blow Moulding
Automatic: Yes Condition: New
Specifications
1.High Automatization
2.High Intelligence
3.Automatic PET blowing machine
4.High output
Machine Features:
1.Satisfaction with different atmospheric pressure for blowing and mechanical action by dividing the blowing and action into three parts in the air pressure diagram of the machine.
2.Low cost, high efficiency, easy operation, easy maintenance, etc, with automatic technological process.
3. Low damage rate: less than 0.2 percent.
4. Stable performance with advanced PLC
5. Strong penetrability and good and swift distribution of the heat by letting the bottles rotate by itself and revolute in the rails simultaneously in the infrared preheater.
6. High adjustability to enable the preheater to preheat preforms in shapes by adjusting the light tube and the length of the reflecting board in the preheating area, and eternal temperature in the preheater with an automatic thermostatic apparatus.
7. Two ways of operating: automatic and manual.
8. No contamination and low noise with the air cylinder to drive the action instead of the oil pump.
9. Conveying preforms automatically with conveyor.
10.Strong clamping force with high pressure and double crank links to lock the mold.
11. Low rejection rate: less than 0.2 percent.
12.Contamination is avoided for the bottle body.
13. Easy installation and starting
14. Ideal effect of the chilling with the chilling system.


Technical Parameter:
ITEMCY-VI-A6000
Theoretical output6000
Max.container volume1.25L
Max.neck diameter38MM
Max.container diameter96MM
Max.container height320MM
Number of cavity6
Number of lamp40
Max.heating power35KW
Installation power80KW
Actual power consumption24KW(500cc18g)
Operatating low pressure0.7Mpa
Low pressure consuming2000L/min
Blowing pressure3.5Mpa
High pressure consuming5500L/min
Operating pressure0.3-0.5Mpa
Temperature10
Machine dimension4.2×3.1×3.0
Machine weight5T
