Rotary Packaging Machine For Medicine

Rotary Packaging Machine For Medicine

Quick Details
Place of Origin: China (Mainland) Brand Name: Echo Model Number: echo
Type: Packaging Line Packaging Material: Plastic Automatic Grade: Automatic
Power: 1.5kw Application: Food Condition: New
Packaging Type: bag pouch Driven Type: Electric packaging machine material: stainless steel
PLC control: 2012 food packaging machinery filling and sealing packaging machine: Double f... srand up pouch packaging machine: 2012roary pac...
liquid packaging machine: food rotary packing m...
Specifications
1.high quality,good packing appearance
2.low noise
3.prompt shipment
4.PLC control,CE

Rotary Packaging Machine For Medicine can fill objects into premade bags or premade pouches and seal the bags or pouches


Rotary Packaging Machine For Medicine
Functions and features:
1) Packaging procedures: clip the bag, print codes, open bags, filling1, filling2,heat
and sealing1, heat and sealing2,forming and output packages.
2) Totally automatically controlled by computer: adopts imported PLC and actuator,
with reliable and safe operation and easy maintenance, without pollution.
3) Adopts frequency governor to regulate the speed.
4) Good sealing quality and very low bag broken rate.
5) The shaping step is especially designed to keep the sealing from breaking, so
the sealing is flat and smooth.
6) The machine body adopts advanced plastic spraying technology, while the parts
that contact the materials are made of stainless steel, so it has a good standard
hygiene, anticorrosive property and long service time.
7) According to the packing materials' demands, you can choose automatic metering
mechanism, automatic screw filling machine, intelligent function scale and other
products suitable for automatic metering, which are combined into an automatic
assembly line (also can pack through manual material feeding).


ModelMR8-200Y
No. of working stationEight
Bags sizeW:80-200  L:no limit
Filling Volume5-1500g(depending on type pf product)
Packaging MaterilasZipper bag, stand-up bag, spout bags etc
Capacity30-45bags/min(depending on type of product and packaging material used)
Total power consumption5Kw
Weight accuracyR≤±1
Typical Flow Chart
1, Giving bag
2 ,Hot Foil Coding
3 ,Bags Opening
4 ,Fill one consolidate
5,Fill two
6, Heat sealing one
7,Heat sealing two
8,Forming and output product
