LSG-C Series Tablet/Capsule Counting and Filling Machine

LSG-C Series Tablet/Capsule Counting and Filling Machine

Quick Details
Place of Origin: Liaoning China (Mainland) Brand Name: sinoped Model Number: LSG-C Series
Type: Filling Machine Automatic Grade: Automatic Power: 3.8-7.2KW
Application: Chemical Condition: New Packaging Type: tablet
Driven Type: Electric Counting Range: 15-9999 Vessel Diameter: 25-75 mm
Compress Air Pressure: 0.4-0.6 Mpa Power Supply: AC 380V 3P 50-60 Hz Power Consumption: 3.8-7.2kw
Nmber of Slots: 12-24

Specifications
it is specialized for counting the products of medicine, health care, food and so on.
LSG-C Series Tablet/Capsule Counting and Filling Machine

General Description:
LSG-C Series Tablet/Capsule Counting and Filling Machine is specialized for counting the products of medicine, health care, food, agricultural chemicals, chemical engineering and so on. For example: tablets, coated tablets, soft/hard capsules. The machine can be used alone as well as with other machines produced by our company to form a complete producing line.

LSG-C Series Tablet/Capsule Counting and Filling Machine is composed of machine box, two-layer vibrator mechanism, photoelectric counting system, cylinder and electromagnetic valve system, controlling box, conveyor, sensors and so on. Users are able to control the whole working process of the machine through user interface. High speed PLC system controls the whole process including counting, filling and monitoring. The machine counts precisely, quickly on both common capsules and transparent ones (of weird shapes).

LSG-C Series Tablet/Capsule Counting and Filling Machine has material container, material delivery pad, photoelectric counting channels and cylinders which can be detached easily without using tools and cleaned conveniently. Solenoid valves controls the cylinders to loosen or tighten the material delivery pad.

LSG-C Series Tablet/Capsule Counting and Filling Machine has sensors to monitor the material funnel. When the bottle arrives below the funnel, the funnel comes down and covers the bottle neck, opening the funnel valve and the counted pills inside the funnel will drop into the bottle swiftly. If the height of bottles is changed, users need only to adjust the height of the working platform on the interface.

LSG-C Series Tablet/Capsule Counting and Filling Machine is a new, precise and stable machine which is prior to other similar types of counters of our company.

Technical Parameters:
Number of slots
LSG-12C
LSG-16C
LSG-24C
Nmber of Slots
12
16
24
Capacity (Per Hour)
48,000-240,000
60,000-320,000
80,000-500,000
Counting Range
15-9999
Tablet/Capsule Size
Tablet/pill: δmin: 3mm Φ max: 22mm capsule: 00#-5#
Vessel Diameter
Φ 25-Φ 75 mm
Vessel Height
≤240 mm
Feeding Hopper
40L
40L X 2
Compress Air Pressure
0.4-0.6 Mpa
Air Consumption
150L/min
200L/min
250L/min
Power Supply
AC 380V 3P 50-60 Hz
Power Consumption
3.8 KW
4.0KW
7.2 KW
Dimension (L×W×H)
1200×1950×1800mm
1300×1950×1800mm
1650×1950×1800mm

The capacity depends on the size, shape, the number of lanes and the volume of bottles
