Stainless steel herbal medicine rotary vibration filter screening machine

Stainless steel herbal medicine rotary vibration filter screening machine


Quick Details
Place of Origin: Henan China (Mainland) Brand Name: Tongxin Model Number: XZS
Type: Grain Processing Equipment Model: 600/800/1000/1200/1500/1800/2000 Screen Size: 2-600mesh
Layers: 1-5 Vibration Motor Power: 0.55-3.7kw Material: Carbon steel,Stainless steel
Specifications
1.Screening,filtering,grading,classifying materials
2.For grain,food,fruit,juice,powder,etc.
3.High quality and efficiency
Role and PrinciplesVibration screening filter the basic principle of the electrical axis of the heavy hammer to install (unbalanced heavy hammer),
the motor rotary motion into horizontal, vertical, tilt three movement, then this movement passed to the
screen surface. Adjust the upper and lower ends of heavy hammer of the phase angle, can change the screen
surface materials in the trajectories.
16 szx0
Technical parameters

Model
60080010001200150018002000
The effective diameter of screen surface(mm)5407309001100140017001886
Effective screening Area0.22810.41830.63590.94991.53862.26872.7922
Screen Size                  2 - 600 mesh
Layers1-51-51-51-51-51-31-3
Power(kw)Vibration Motor0.550.751.11.52.23.03.7
General Electric0.751.11.51.52.22.23.0
Main Features
• High efficiency ,compact and durable design, any powder type ,mucus can be screened.
• Changer easy, simple, easy to clean.
• Mesh do not block, powder does not fly, can be screened up to 600mesh or 20 micro
• Impurities and coarse materials automobile exhaust can be a continuous operation.
• Unique grid design and screen long-term use of time, just 3-5 minutes fast changing networks.
• Small and easy to move do not take up space.
• Screen machines can reach a maximum five-story, it is recommended to use three-tier
Application industry
•The food industry: powdered sugar, starch, salt, rice flour, milk powder, soya-bean milk, egg powder,
soy sauce, fruit juice, icing sugar ,stevia sugar,stevia powder,ginger,potato,cassava powder,
grape seed,peanut,groundnut,arachis,etc.
•Chemical industry: resin, coating, industrial pharmaceutical, cosmetic, paint, raw coal ,etc.
The structure
xzs01_jpg
The pictures
20.05  002
